Glaser GRS 33 Pipe Grinding Machine
Used Glaser GRS 33 pipe bend grinding machine for smoothing round or elliptical tube bends from 10mm to 80mm diameter.
Brand:
Glaser
Model:
GRS 33
Condition:
Not sure what Machine, Parts, or Tooling you need? We can help!
Used Pipe bend grinding machine Glaser GRS 33
Wet grinding device
Foot switch
Workpieces from Ø 10mm to Ø 80mm
Drive motor: 2.2 kW
Revolutions: 1450 rpm.
Power supply: 380-400 V three-phase, 16 A, 50 Hz
Weight: approx. 165 kg
The GRS 33 pipe bend grinding machine is suitable for grinding round or elliptical workpieces such as pipes or round material made of stainless steel, iron, aluminum, brass, copper and wood.
The pipe cross-section can be round or elliptical. The pipe bend can be up to approximately 140°. (The exact angle depends on the pipe diameter.)
The pipe bends can be ground dry or wet. The grinding machine is equipped with a coolant system for wet grinding.
Model: GRS 33
Workpiece Range: Ø 10mm – Ø 80mm
Max Bend Angle Ground: ~140° (depends on pipe diameter)
Drive Motor: 2.2 kW
Speed: 1,450 rpm
Electrical: 380-400V, 3-phase, 16A, 50Hz
Approx. Weight: 165 kg
Features: Wet grinding device with coolant system, foot switch, dry grinding capable
