Alpine Bender provides robust and versatile machines that can quickly adapt to a variety of production changes. Aside from reducing labor, our contemporary machines are made to be dependable and serviceable. Each machine is designed to integrate quick tool-changing features and rapid parts replacement to minimize machine downtime during production.
All CNC Electric Alpine Benders – AE Series
Special features:
- Single rotary bend head for left and right hand bending in one machine
- Up to 14 axis servo driven controls
- Electric carriage booster for difficult or tight radius bending
- Push bend rolling (calendaring)
- Patented planetary gear drive achieve 95% energy efficiency
- Advanced user friendly touch screen IPC with WIN 7 operating system and dynamic machine visual simulation
Advantages:
- Reduced electricity consumption
- Superior controllability and repeatability
- Minimize Interference
- Less tooling setup time, fewer mechanical adjustments
- Clean working environment
- Lowest emission of airborne noise (dBA)
AEMR/AEMR-LR model are fully electric CNC mandrel benders with 3-D graphics programming.
| MODEL | MAX TUBE O.D. | MAX BENDING RADIUS | MAX LENGTH OVER MANDREL | OVERALL L X W X H | TOTAL WEIGHT | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| UNIT | mm | inch | mm | inch | mm | inch | mm | inch | kg | lbs | More Info |
| 15AEMB-LR | 15 x 1.5 | 0.59 x 0.059 | Oct-55 | 0.393 - 2.16 | 1000 | 39.37 | 2700 x 800 x 1400 | 106.3 x 31.4 x 55.1 | 1400 | 2080 | More Info |
| 20EMB-LR | 20 x 1.5 | 0.78 x 0.059 | Oct-70 | 0.39 x 2.75 | 1500 | 59.05 | 3100 x 850 x 1400 | 122.0 x 33.5 x 55.1 | 1500 | 3300 | More Info |
| 30AEMR-LR | 30 x 2.0 | 1.18 x 0.079 | 15 - 90 | 0.59 - 3.541 | 2800 | 110.2 | 4400 x 850 x 1500 | 17.32 x 33.4 x 59.0 | 1400 | 3080 | More Info |
| 45AEMR-LR | 45 x 2.0 | 1.77 x 0.078 | 30 -150 | 1.18 - 5.9 | 3000 | 118.1 | 5200 x 1070 x 1650 | 204.7 x 42.1 x 64.9 | 4400 | 9680 | More Info |
| 75AEMR-LR | 76.2 x 2.0 | 3.0 x 0.079 | 40 - 230 | 1.57 - 9.05 | 3000 | 118.1 | 5000 x 1500 x 2000 | 216.5 x 59.1 x 78.74 | 7000 | 15400 | More Info |
| 50AEMR-RBE | 50.8 x 1.8 | 2.0 x 0.070 | 30 - 150 | 1.18 - 5.9 | 3200 | 125.9 | 5500 x 1500 x 1520 | 216 x 59.8 x 59 | 3100 | 6820 | More Info |
| 80AEMR-RBE | 80 x 2.0 | 3.15 x 0.079 | 40 - 230 | 1.57 - 9.05 | 4000 | 157.4 | 5000 x 1500 x 1800 | 216.5 x 59.1 x 78.74 | 7000 | 15400 | More Info |
| 100AEMR-RBE | 100 x 3.6 | 4.0 x 0.140 | 30 - 300 | 1.18 - 11.8 | 4000 | 157.4 | 7100 x 1750 x 1820 | 279.5 x 68.9 x 71.65 | 8000 | 17600 | More Info |
Electric CNC Hybrid Alpine Tube Benders – E Series
ED Model
- ED Model is a touch screen control and double stack tooling design with 4 axis Y, B, C, X (bend head horizontal shifting for tool change) driven by A/C servo motor
- Combines two different radii rotary draw bending in same tool stack
- Electric-driven rotary draw bending arm performs with high accuracy, durability and less electricity consumption
- Planetary gears in bend head provide speed reduction and high torque transmission
EBR Model
- EBR Model is a touch screen control and double stack tooling in the same Y, B, C, X (bend head horizontal shifting for tool change) driven by A/C servo motor
- Combines rotary draw bending and push bending (calendaring) in same tool stack
- Electric-driven rotary draw bending arm performs with high accuracy, durability and less electricity consumption
- Planetary gears in bend head provide speed reduction and high torque transmission
ETR Model
- ETR Model is a touch screen control and triple stack tooling design with 4 axis Y, B, C, X (bend head horizontal shifting for tool change) driven by A/C servo motor
- Combines rotary draw bending and push bending (calendaring) in same tool stack
- Electric-driven rotary draw bending arm performs with high accuracy, durability and less electricity consumption
- Planetary gears in bend head provide speed reduction and high torque transmission
EMB-V/EMR-V Model
- EMB-V/EMR-V Model is a touch screen control and double stack tooling design with 5 axis Y, B, C, X, Z (bend head horizontal and vertical shifting for tool change) driven by A/C servo motor
- Combines rotary draw bending and push bending (calendaring) in same tool stack
- Electric-driven rotary draw bending arm performs with high accuracy, durability and less electricity consumption
- Planetary gears in bend head provide speed reduction and high torque transmission
- Series Models
- Multi Stack EMR-V / EMB-V Specs
- Triple Stack ETR Specs
- Double Stack Rolling EBR Specs
- Double Stack ED Specs
| MODEL | MAX TUBE O.D. | MAX. BENDING RADIUS | MAX. LENGTH OVER MANDREL | OVERALL L X W X H | TOTAL WEIGHT | |||||
|---|---|---|---|---|---|---|---|---|---|---|
| UNIT | mm | inch | mm | inch | mm | inch | mm | inch | kg | lbs |
| 18EMB-V | 18 x 1.6 | 0.71 x 0.062 | 10 - 80 | 0.39 - 3.15 | 1200 | 47.24 | 2950 x 800 x 1200 | 112.2 x 31.5 x 47.2 | 850 | 1870 |
| 25EMB/R-V | 25.4 x 1.5 | 1.0 x 0.059 | 15 - 120 | 0.59 - 4.72 | 1500 | 59.05 | 3300 x 820 x 1200 | 129.9 x 36.2 x 47.2 | 1200 | 2640 |
| 30EMB/R-V | 30 x 2.0 | 1.18 x 0.079 | 15 - 120 | 0.59 - 4.72 | 2000 | 78.74 | 4030 x 720 x 1300 | 158.6 x 28.3 x 51.2 | 1700 | 3740 |
| 38EMB/R-V | 38.1 x 1.8 | 1.5 x 0.071 | 25 - 150 | 0.98 - 5.9 | 2200 | 86.6 | 4200 x 900 x 1400 | 165.3 x 35.4 x 55.1 | 2080 | 4576 |
| 50EMB/R-V | 50.8 x 2.0 | 2.0 x 0.079 | 30 - 220 | 1.18 - 8.66 | 2500 | 98.4 | 4650 x 1200 x 5100 | 183.1 x 47.2 x 59.0 | 3100 | 6820 |
| 65EMB/R-V | 65 x 2.5 | 2.56 x 0.098 | 35 - 250 | 1.38 - 9.84 | 2500 | 98.4 | 6150 x 1650 x 1500 | 242.1 x 64.9 x 61.0 | 4280 | 9416 |
| 80EMB/R-V | 80 x 2.5 | 3.15 x 0.098 | 40 - 280 | 1.57 - 11.0 | 3500 | 137.8 | 6350 x 1750 x 2050 | 250 x 68.8 x 80.7 | 5890 | 12958 |
| 100EMB/R-V | 100 x 3.6 | 4.0 x 0.141 | 30 - 300 | 1.18 - 11.8 | 3500 | 137.8 | 7050 x 1550 x 1850 | 277.5 x 61.0 x 72.8 | 7500 | 16500 |
| 130EMB/R-V | 127 x 3.8 | 5.0 x 0.15 | 80 - 400 | 3.15 - 15.74 | 4000 | 157.5 | 8100 x 2000 x 2200 | 318.78.7 x 86.6 | 12500 | 27500 |
| 150 EMB/R-V | 152.4 x 3.0 | 6.0 x 0.12 | 90 - 400 | 3.54 - 15.74 | 4000 | 157.5 | 8100 x 2300 x 2100 | 318 x 90.5 x 82.6 | 14000 | 30800 |
| MODEL | MAX TUBE O.D. | MAX BENDING RADIUS | MAX LENGTH OVER MANDREL | OVERALL L X W X H | TOTAL WEIGHT | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| UNIT | mm | inch | mm | inch | mm | inch | mm | inch | kg | lbs | |
| 25ETR | 25.4 x 1.5 | 1.0 x 0.059 | 15 - 120 | 0.59 - 4.72 | 1500 | 59.05 | 3300 x 920 x 1200 | 129.9 x 36.2 x 47.2 | 1200 | 2640 | More Info |
| 30ETR | 30 x 2.0 | 1.18 x 0.079 | 15 - 120 | 0.59 - 4.72 | 2200 | 86.61 | 4030 x 720 x 1300 | 158.6 x 28.3 x 51.2 | 1700 | 3740 | More Info |
| 38ETR | 38.1 x 1.8 | 1.5 x 0.071 | 25 - 150 | 0.98 - 5.9 | 2200 | 86.6 | 4200 x 900 x 1400 | 165.3 x 35.4 x 55.1 | 2080 | 4576 | More Info |
| 50ETR | 50.8 x 2.0 | 2.0 x 0.079 | 30 - 220 | 1.18 - 8.66 | 2500 | 98.4 | 4850 x 1200 x 1500 | 183.1 x 47.2 x 59.0 | 3100 | 6820 | More Info |
| 65ETR | 65 x 2.0 | 2.56 x 0.079 | 35 - 250 | 1.38 - 9.84 | 2500 | 98.4 | 6150 x 1650 x 1500 | 242.1 x 64.9 x 61.0 | 4280 | 9416 | More Info |
| 80ETR | 80 x 2.5 | 3.15 x 0.098 | 40 - 280 | 1.57 - 11.0 | 3500 | 137.8 | 6350 x 1750 x 2050 | 250 x 68.8 x 80.7 | 5890 | 12958 | More Info |
| 100ETR | 100 x 3.0 | 4.0 x 0.118 | 30 - 300 | 1.18 - 11.8 | 3500 | 137.8 | 7050 x 1550 x 1850 | 277.5 x 61.0 x 72.8 | 7500 | 16500 | More Info |
| MODEL | MAX TUBE O.D. | MAX BENDING RADIUS | MAX LENGTH OVER MANDREL | OVERALL L X W X H | TOTAL WEIGHT | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| UNIT | mm | inch | mm | inch | mm | inch | mm | inch | kg | lbs | More Info |
| 25EBR | 25.4 x 1.5 | 1.0 x 0.059 | 15 - 120 | 0.59 - 4.72 | 1500 | 59.05 | 3300 x 920 x 1200 | 129.9 x 36.2 x 47.2 | 1200 | 2640 | More Info |
| 30EBR | 30 x 2.0 | 1.18 x 0.078 | 15 - 120 | 0.59 - 4.72 | 2200 | 86.61 | 4030 x 720 x 1300 | 158.6 x 28.3 x 51.2 | 1700 | 3740 | More Info |
| 38EBR | 38.1 x 1.8 | 1.5 x 0.071 | 25 - 150 | 0.98 - 5.9 | 2200 | 86.6 | 4200 x 1200 x 1500 | 165.3 x 35.4 x 55.1 | 2080 | 4576 | More Info |
| 50EBR | 50.8 x 2.0 | 2.0 x 0.079 | 30 - 220 | 1.18 - 8.66 | 2500 | 98.4 | 4650 x 1200 x 1500 | 183.1 x 47.2 x 59.0 | 3100 | 6820 | More Info |
| 65EBR | 65 x 2.0 | 2.56 x 0.079 | 35 - 250 | 1.38 - 9.84 | 2500 | 98.4 | 6150 x 1650 x 1500 | 242.1 x 64.9 x 61.0 | 4280 | 9416 | More Info |
| 80EBR | 80 x 2.5 | 3.15 x 0.098 | 40 x 280 | 1.57 - 11.0 | 3500 | 137.8 | 6350 x 1750 x 2050 | 250 x 68.8 x 80.7 | 5890 | 12958 | More Info |
| 100EBR | 100 x 3.0 | 4.0 x 0.118 | 30 - 300 | 1.18 - 11.18 | 3500 | 137.8 | 7050 x 1550 x 1850 | 277.5 x 61.0 x 72.8 | 7500 | 16500 | More Info |
| 130EBR-RBE | 127 x 3.8 | 5.0 x 0.15 | 80 - 400 | 3.15 - 15.74 | 4000 | 157.5 | 1100 x 2000 x 2200 | 433 x 78.7 x 86.5 | 11000 | 24200 | More Info |
| MODEL | MAX TUBE O.D. | MAX BENDING RADIUS | MAX LENGTH OVER MANDREL | OVERALL L X W X H | TOTAL WEIGHT | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| UNIT | mm | inch | mm | inch | mm | inch | mm | inch | kg | lbs | |
| 12ED | 12 x 1.0 | 0.5 x 0.039 | Dec-55 | 0.47 - 2.16 | 1000 | 39.37 | 3700 x 1100 x 1300 | 145.6 x 43.3 x 51.1 | 1400 | 3080 | More Info |
| 18ED | 18 x 1.6 | 0.71 x 0.062 | Oct-80 | 0.39 - 3.15 | 1200 | 47.24 | 4030 x 1200 x 1350 | 158.6 x 47.2 x 53.1 | 2500 | 5500 | More Info |
| 25ED | 25.4 x 1.5 | 1.0 x 0.059 | 15 - 120 | 0.59 - 4.72 | 1500 | 59.05 | 4800 x 1400 x 1350 | 168.9 x 55.1 x 53.1 | 3000 | 6600 | More Info |
| 30ED | 30 x 2.0 | 1.18 x 0.079 | 15 - 120 | 0.59 - 4.72 | 2200 | 86.61 | 5500 x 1500 x 1500 | 216.5 x 59.1 x 59.1 | 4000 | 8800 | More Info |
| 38ED | 38.1 x 1.8 | 1.5 x 0.071 | 25 - 150 | 0.98 - 5.9 | 2200 | 86.61 | 4200 x 900 x 1400 | 165.3 x 35.4 x 55.1 | 2080 | 4576 | More Info |
| 50ED | 50.8 x 2.0 | 2.0 x 0.079 | 30 - 220 | 1.18 - 8.66 | 2500 | 98.43 | 4650 x 1200 x 1500 | 183.1 x 47.2 x 59.0 | 3100 | 6820 | More Info |
| 65ED | 65 x 2.0 | 2.56 x 0.079 | 35 - 250 | 1.38 - 9.84 | 2500 | 98.4 | 6150 x 1650 x 1500 | 242.1 x 64.9 x 61.0 | 3800 | 8360 | More Info |
| 80ED | 80 x 2.5 | 3.15 x 0.098 | 40 - 280 | 1.57 - 11.0 | 3500 | 137.8 | 6350 x 1750 x 2050 | 250 x 68.8 x 80.7 | 5600 | 12320 | More Info |
| 100ED | 100 x 3.0 | 4.0 x 0.118 | 30 - 300 | 1.18 - 11.18 | 3500 | 137.8 | 7050 x 1550 x 1750 | 277.6 x 61.0 x 68.9 | 7500 | 16500 | More Info |
CNC Hydraulic Alpine Tube Benders – H Series
HS Model
- HS model is a touch screen control and single stack tooling design. Y (feeding) and B (rotation) axis driven by A/C servo motor with C (bending) axis driven by proportional hydraulic system
- Excellent performance on accuracy, durability and suitable for high production manufacturing.
HD Model
- HD model is a touch screen control and double stack tooling design. Y (feeding) and B (rotation) axis driven by A/C servo motor with C (bending) axis driven by proportional hydraulic system
- Combines two different radii rotary draw bending in same tool stack
- Excellent performance on accuracy, durability and suitable for high production manufacturing
HS-P/HD-P Model
- HS-P/HD-P model is a touch screen PLC control and single stack tooling design. Y (feeding) and B (rotation) axis driven by A/C servo motor with C (bending) axis driven by hydraulic system HD-P Model is a touch screen PLC control with double stack tooling design.
- Economic and affordable model with excellent accuracy and durability
- Suitable for high production manufacturing
| MODEL | MAX TUBE O.D. | MAX BENDING RADIUS | MAX LENGTH OVER MANDREL | OVERALL L X W X H | TOTAL WEIGHT | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| UNIT | mm | inch | mm | inch | mm | inch | mm | inch | kg | lbs | |
| 38HD | 38.1 x 3.0 | 1.5 x 0.118 | 25 - 150 | 0.98 - 5.91 | 2200 | 86.6 | 4000 x 1100 x 1300 | 157.4 x 43.3 x 51.1 | 1700 | 3740 | More Info |
| 50HD | 50.8 x 3.0 | 2.0 x 0.118 | 30 - 220 | 1.18 - 8.66 | 2200 | 86.6 | 4200 x 1200 x 1350 | 165.3 x 47.2 x 53.1 | 2800 | 6160 | More Info |
| 65HD | 65 x 3.0 | 2.56 x 0.118 | 35 - 250 | 1.38 - 9.84 | 2500 | 98.4 | 4800 x 1500 x 1600 | 188.9 x 59.0 x 63.0 | 3500 | 7700 | More Info |
| 80HD | 80 x 4.5 | 3.15 x 0.177 | 40 - 280 | 1.57 - 11.02 | 3000 | 118.1 | 5600 x 1700 x 1800 | 220.4 x 66.9 x 62.9 | 5000 | 11000 | More Info |
| 100HD | 101.6 x 5.5 | 4.0 x 0.216 | 60 - 400 | 2.36 - 15.75 | 3600 | 141.7 | 7000 x 1700 x 1800 | 275.5 x 66.9 x 70.8 | 6000 | 13200 | More Info |
| 120HD | 120 x 5.5 | 5.0 x 0.216 | 80 - 400 | 3.15 - 15.7 | 5000 | 196.8 | 6500 x 2150 x 1750 | 334.6 x 84.6 x 68.8 | 12500 | 27500 | More Info |
| 130HM-V | 130 x 4.5 | 5.12 x 0.177 | 80 - 300 | 3.15 - 11.81 | 5000 | 196.8 | 10200 x 2310 x 2300 | 401.5 x 90.9 x 90.5 | 18400 | 40480 | More Info |
| 150HM-V | 152.4 x 7.0 | 6 x 0.275 | 90 -400 | 3.54 - 23.6 | 6000 | 236.2 | 9500 x 2500 x 2500 | 374 x 98.4 x 98.4 | 19400 | 42680 | More Info |
| MODEL | MAX TUBE O.D. | MAX BENDING RADIUS | MAX LENGTH OVER MANDREL | OVERALL L X W X H | TOTAL WEIGHT | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| UNIT | mm | inch | mm | inch | mm | inch | mm | inch | kg | lbs | |
| 38HD-P | 38.1 x 3.0 | 1.5 x 0.118 | 25 - 150 | 0.98 - 5.91 | 2200 | 86.6 | 4000 x 1100 x 1300 | 157.4 x 43.3 x 51.1 | 1700 | 3740 | More Info |
| 50HD-P | 50.8 x 3.0 | 2.0 x 0.118 | 30 - 220 | 1.18 - 8.66 | 2200 | 86.6 | 4200 x 1200 x 1350 | 165.3 x 47.2 x 53.1 | 2800 | 6160 | More Info |
| 65HD-P | 65 x 3.0 | 2.56 x 0.118 | 35 - 250 | 1.38 - 9.84 | 2500 | 98.4 | 4800 x 1500 x 1600 | 188.9 x 59.0 x 63.0 | 3500 | 7700 | More Info |
| MODEL | MAX TUBE O.D. | MAX BENDING RADIUS | MAX LENGTH OVER MANDREL | OVERALL L X W X H | TOTAL WEIGHT | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| UNIT | mm | inch | mm | inch | mm | inch | mm | inch | kg | lbs | |
| 38HS-P | 38.1 x 3.0 | 1.5 x 0.118 | 25 - 150 | 0.98 - 5.91 | 2200 | 86.6 | 3700 x 1100 x 1300 | 145.6 x 43.3 x 51.1 | 1400 | 3080 | More Info |
| 50HS-P | 50.8 x 3.0 | 2.0 x 0.118 | 30 - 220 | 1.18 - 8.66 | 2200 | 86.6 | 4030 x 1200 x 1350 | 158.6 x 47.2 x 53.1 | 2500 | 5500 | More Info |
| 65HS-P | 65 x 3.0 | 2.56 x 0.118 | 35 - 250 | 1.39 - 9.84 | 2500 | 98.4 | 4800 x 1400 x 1350 | 188.9 x 55.1 x 53.1 | 3000 | 6600 | More Info |
| 80HS-P | 80 x 4.5 | 3.15 x 0.177 | 40 - 280 | 1.57 - 11.02 | 3000 | 118.1 | 5500 x 1500 x 1500 | 216.5 x 59.0 x 59.0 | 4000 | 8800 | More Info |
| MODEL | MAX TUBE O.D. | MAX BENDING RADIUS | MAX LENGTH OVER MANDREL | OVERALL L X W X H | TOTAL WEIGHT | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| UNIT | mm | inch | mm | inch | mm | inch | mm | inch | kg | lbs | |
| 38HS | 38.1 x 3.0 | 1.5 x 0.118 | 25 - 150 | 0.98 - 5.91 | 2200 | 86.6 | 3700 x 1100 x 1300 | 145.6 x 43.3 x 51.1 | 1400 | 3080 | More Info |
| 50HS | 50.8 x 3.0 | 2.0 x 0.118 | 30 - 220 | 1.18 - 8.66 | 2200 | 86.6 | 4030 x 1200 x 1350 | 158.6 x 47.2 x 53.1 | 2500 | 5500 | More Info |
| 65HS | 65 x 3.0 | 2.56 x 0.118 | 35 - 250 | 1.39 - 9.84 | 2500 | 98.4 | 4800 x 1400 x 1350 | 168.9 x 55.1 x 53.1 | 3000 | 6600 | More Info |
| 80HS | 80 x 4.5 | 3.15 x 0.177 | 40 - 280 | 1.57 - 11.02 | 3000 | 118.1 | 5500 x 1500 x 1500 | 216.5 x 59.1 x 59.1 | 4000 | 8800 | More Info |
| 100HS | 101.6 x 5.5 | 4.0 x 0.216 | 60 - 400 | 2.36 - 15.75 | 3600 | 141.7 | 6500 x 1600 x 1550 | 255.9 x 62.9 x 61.0 | 6000 | 13200 | More Info |
| 120HS | 120 x 5.5 | 4.7 x 0.216 | 80 - 450 | 3.15 - 17.71 | 5000 | 196.9 | 8000 x 1800 x 1600 | 314.9 x 70.8 x 62.9 | 8000 | 17600 | More Info |
| 150HS | 152.4 x 7.0 | 6.0 x 0.275 | 90 - 500 | 3.54 - 19.69 | 6000 | 236.2 | 9000 x 2100 x 1700 | 354.3 x 82.6 x 66.9 | 9500 | 20900 | More Info |
| 180HS | 180 x 9.0 | 7.08 x 0.35 | 100 - 600 | 3.93 - 23.6 | 6000 | 236.2 | 10000 x 2100 x 2150 | 393.7 x 82.6 x 84.6 | 18000 | 39600 | More Info |
| 220HS | 220 x 15 | 8.66 x 0.59 | 100 - 800 | 3.93 - 31.5 | 6000 | 236.2 | 10000 x 3200 x 2100 | 393.6 x 125.9 x 82.6 | 23000 | 50800 | More Info |
All NC Two and Single Axis Hydraulic Alpine Tube Benders – NC Series
NC Series
Full electric CNC mandrel bender with 3D graphics programming.
Special Features
- Single Rotary bend head for left and right-hand bending in one machine
- Up to 14-axis servo-driven controls
- RBE – Electric carriage booster for difficult or tight radius bending
- Push bend rolling (calendaring)
- Patented planetary gear drive achieve 95% energy efficiency
- Advanced user-friendly touch screen IPC with Windows 7 operating system and dynamic machine visual simulation.
| MODEL | MAX TUBE O.D. | MAX BENDING RADIUS | MAX LENGTH OVER MANDREL | OVERALL L X W X H | TOTAL WEIGHT | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| UNIT | mm | inch | mm | inch | mm | inch | mm | inch | kg | lbs | More Info |
| AB38NC | 38.1 x 3.0 | 1.5 x 0.118 | 25 -170 | 0.98 - 6.6 | 1900 | 74.8 | 2600 x 900 x 1100 | 102.4 x 35.4 x 43.3 | 850 | 1870 | More Info |
| AB50NC | 50.8 x 3.0 | 2.0 x 0.118 | 30 - 250 | 1.18 - 11.81 | 2200 | 86.6 | 3000 x 900 x 1200 | 118.1 x 35.4 x 47.2 | 950 | 2090 | More Info |
| AB75NC | 76.2 x 3.0 | 3.0 x 0.118 | 40 - 300 | 1.57 - 11.81 | 2600 | 102.4 | 3600 x 1200 x 1200 | 141.7 x 47.2 x 47.2 | 1900 | 4180 | More Info |
| AB89NC | 88.9 x 2.5 | 3.5 x 0.157 | 40 - 350 | 1.57 - 13.77 | 2600 | 102.4 | 3700 x 1200 x 1200 | 145.7 x 47.2 x 47.2 | 2200 | 4840 | More Info |
| AB100NC | 101.6 x 5.5 | 4.0 x 0.217 | 60 - 400 | 2.3 - 15.7 | 3600 | 141.7 | 4800 x 1500 x 1400 | 188.9 x 59.1 x 55.1 | 4500 | 9900 | More Info |
| AB120NC | 127 x 3.5 | 5.0 x 0.217 | 80 - 450 | 3.15 - 19.68 | 5200 | 204.7 | 7000 x 1700 x 1600 | 275.5 x 66.9 x 63.0 | 7200 | 15840 | More Info |
| AB150NC | 152.4 x 7.0 | 6.0 x 0.275 | 90 - 550 | 3.5 - 21.6 | 6000 | 236.2 | 8100 x 2100 x 1700 | 318.8 x 82.6 x 66.9 | 9000 | 19800 | More Info |
| AB180NC | 180 x 9.0 | 7.0 x 0.275 | 100 - 600 | 3.93 - 23.6 | 6000 | 236.2 | 8100 x 2300 x 1700 | 318.8 x 90.6 x 66.9 | 9800 | 21560 | More Info |
| AB220NC | 220 x 8.0 | 8.6 x 0.275 | 100 - 700 | 4.72 - 34.6 | 6000 | 236.2 | 10000 x 2300 x 1900 | 393.7 x 90.6 x 74.8 | 16500 | 36300 | More Info |
Twin Head Alpine Tube Benders – T Series
The Alpine T Series tube bender is a high-performance, twin-head bending machine designed for simultaneous bending. It’s particularly suited for applications requiring symmetrical bending, such as automotive exhaust systems, offering precision and rapid processing to meet high-volume production needs.
| MODEL | MAX TUBE O.D. | MAX BENDING RADIUS | MULTI TUBE BENDING - OD 3/4" | MULTI TUBE BENDING - OD 7/8" | MULTI TUBE BENDING - OD 1" | MULTI TUBE BENDING - OD 1-1/2" | OVERALL L X W X H | TOTAL WEIGHT | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| UNIT | mm | inch | mm | inch | pc | pc | pc | pc | mm | inch | kg | lbs | |
| T38 | 38.1 x 2.5 | 1.5 x 0.098 | 38 - 180 | 0.98 - 6.6 | 3~4 | 2~3 | 1~2 | 1 | 1900 x 1000 x 1500 | 174.8 x 39.4 x 59.1 | 1000 | 2200 | More Info |
| T50 | 50 x 1.6 | 2.0 x 0.063 | 40 - 250 | 1.57 - 9.84 | 4~5 | 3~4 | 2~3 | 1~2 | 2800 x 1400 x 1800 | 110.2 x 55.1 x 70.8 | 1800 | 3960 | More Info |
| T38-90 | 38 x 2.5 | 1.5 x 0.098 | 38 - 180 | 0.98 - 6.6 | 3~4 | 2~3 | 1~2 | 1 | 1900 x 1000 x 1500 | 174.8 x 39.4 x 59.1 | 1000 | 2200 | More Info |
| CNCT38-4A | 38 x 2.5 | 1.5 x 0.098 | 38 ~ 180 | 1.5 - 6.6 | 2-3 | 1-2 | 1-2 | 1 | 7000 x 1200 x 1500 | 275.6 x 47.2 x 59.1 | 2100 | 4620 | More Info |
| CNCT38-5A | 38 x 2.5 | 1.5 x 0.098 | 38 ~ 180 | 1.5 - 6.6 | 2-3 | 1-2 | 1-2 | 1 | 7000 x 1200 x 1500 | 275.6 x 47.2 x 59.1 | 2200 | 4840 | More Info |
Not sure what Machine, Parts, or Tooling you need? We can help!
Fiber Laser Alpine Tube Cutters – LS Series
Alpine LS Series fiber laser tube cutters cut, notch, and profile round and shaped tube in one automated cycle. Two lines are available: 5-axis machines for 3D bevel cutting, and 4-axis machines for straight-cut profiling.
LS-5E 3D Tube Laser (5-Axis)
- The tilting Precitec laser head rotates ±45° on the A-axis, so the machine can cut weld-prep bevels, angled ends, and 3D profiles that a 4-axis machine can’t reach. This often removes a secondary beveling or deburring step.
- Three self-centering chucks with zero end waste cutting
- Automatic bundle loading with weld seam detection
- Servo-driven unloading supports finished parts through the cut
- Handles round, square, rectangular, elliptical, obround, and asymmetrical tube
LS-4 Tube Laser (4-Axis)
- The fiber laser head runs servo-driven axes at up to 500 mm/s. It cuts holes, slots, notches, and copes in tube at ±0.0012″ repeatability.
- Fiber laser options from 1,000W to 3,000W
- Capacities from 0.79″ up to 8.19″ OD
- Servo carriage feeds at up to 834 mm/s
- Loads raw tube up to 236″ long
Special features:
- ±0.0012″ positioning repeatability
- Servo-driven fiber laser head
- Round and shaped tube cutting
- Up to 248″ raw tube length
| Specification | LS208-4C Fiber Laser | LS150-4C FiberLaser | LS220-5E Fiber Laser | LS150-5EFiberLaser |
|---|---|---|---|---|
| Cutting Capacity/OD | 0.71" ~8.19" | 0.71" ~6.0" | 0.71" ~8.66" | 0.63" ~6.0" |
| Standard raw tube loading length | 248.03" | 248.03" | 248.03" | 248.03" |
| Min rear end waste | 2.95" | 1.77" | 30.12" | 25.59" |
| X-axis working distance | 8.66" | 7.87" | 10.63" | 6.3" |
| X-axis speed | 19.69"/sec | 19.69"/sec | 9.84"/sec | 9.84"/sec |
| Z-axis working distance | 5.91" | 4.33" | 15.12" | 12.20" |
| Z-axis speed | 19.69"/sec | 19.69"/sec | 13.86"/sec | 13.86"/sec |
| Y-axis working distance | 271.65" | 271.65" | ±45 degree | ±45 degree |
| Y-axis speed | 32.80"/sec | 30.63"/sec | 360 degree/sec | 360 degree/sec |
| Position repeatability | ±0.0012" | ±0.0012" | 275.98"/355.91"/255.91" | 279.53"/354.53"/208.66" |
| B-axis speed | 450 degrees/sec | 450 degrees/sec | 30.59"/sec | 30.59"/sec |
| B-axis positioning repeatability | ±8 archmin | ±8 archmin | ±0.0012" | ±0.0012" |
| Laser head | Precitec | Precitec | 450 degrees/sec | 600 degrees/sec |
| Laser source | IPG/Raycus | IPG/Raycus | ±8 archmin | ±8 archmin |
| Machine size | 440.94" x 82.68" x 86.61" | 440.94" x 70.87" x 82.68" | 527.56" x 149.61" x 106.30" | 444.88" x 110.24" x 102.36" |
| Machine weight | 2363.63 lbs | 2363.63 lbs | 3636.36 lbs | 3636.36 lbs |
Not sure what Machine, Parts, or Tooling you need? We can help!
End Formers
Multi-Hit End Form Machine
The Alpine End Forming Machines offer high-efficiency tube end forming with multiple forming stations and advanced PLC control. Designed to optimize space and performance, it is ideal for industries requiring precise and consistent end forming.
Special Features
- Tough screen PLC control
- Servo driven positioning
- Continuous multiple hits
- Suitable for swaging, expanding, and flaring
Series Models and Specifications
[table “EFSeries” not found /]
